Maximum Voltage:
90-125 VAC r.m.s. unregulated (US)
220-240 VAC r.m.s. unregulated (AS)
Current Ratings:
Input current maximum: 20A (US)
Peak instantaneous current @ 10ms: >1000A
Output current max: 20A
Transient Suppression:
Maximum transient pulse: 40,000A @ 8/50 μs
Over-Current Protection:
Hydraulic Electromagnetic Breaker
Wiring System:
12-gauge ArNi® conductors
OFE C10100 copper
Ratings: 600 V 105° C
Noise Suppression:
Input to Output (100 kHz – 30 MHz): > 40 dB reduction
Zone to Zone (100 kHz – 30 MHz): > 30dB reduction
Noise Reduction Technology:
NIC™ Noise Isolation Chambers (patented)
Trident Transient Protection Module
CCI™ v4 Noise Filters (3)
KPIP™ Process
Connectors & Outlets:
Inlet: IEC C19R
US Outlets: 8 NEMA5-15P
Vibration Control:
Vibration-damping panels (internal)
Shunyata Isolation Footer
Construction:
Powder coated steel chassis – 16 gauge
Anodized aluminum faceplate
Dimensions:
Width: 17 inches (43.18 cm)
Depth: 6.13 inches (15.57 cm)
Height: 4.58 inches (11.63 cm)
Weight: 9.8 lbs (4.45 kg)
