volume:
Net weight: 2.8kg
Consumption power: 20W
Main Control: Junzheng X1000
Decoding chip: ES9219MQ
Bluetooth: BT 5.0
Power supply: external AC100V-AC240V
Display: Digital Tube Display
Control method: APP+remote control+keys
Enter: CD, U disk, Bluetooth, RCA
Output method: RCA, optical fiber, 3.5mm headset
U disk playback format: DSD / DXD / APE / FLAC / ALAC / WAV / AIFF / AIF / DTS / MP3 / WMA / AAC / OGG / MP2 / M4A / AC3 / OPUS / TAK / Cue
AMP OUT output:
Output Power
50w@82Ω (0.3%)
100W@4Ω (0.3%)
Frequency: 20Hz -20KHz (-0.2DB)
THD+N: 0.003%
Separation: 80db@32Ω
Signal to noise ratio: 108db
PO output:
Output power: 130MW@32Ω
Frequency: 20Hz -40kHz (-0.2DB)
THD+N: 0.0015%
Separation: 75db@32Ω
Dynamic range: 119db
Signal ratio: 118db
Output impedance: less than 1Ω
LO output:
Output level: 2.0VRMS
Frequency: 20Hz -40kHz (-0.2DB)
THD+N: 0.002%
Separation: 85DB
Signal ratio: 116db
