Key Features
50W x 2 Continuous Power into 8 or 4 Ohms90W / 150W / 200W IHF Dynamic Power into 8 / 4 / 2 OhmsFirst hi-fi amplifier to feature Chromecast built-inIntegrated Bluetooth® for added music streaming flexibilityBuilt-in Phono Preamp for TurntablesStereo Line, Optical Digital and Coax Digital inputsNAD Remote App support for tablet and smartphoneDedicated Headphone AmplifierSubwoofer Output
Preamplifier
Line In, Subwoofer Out
THD (20Hz-20kHz)<0.005% at 2V outSignal/Noise Ratio>106dB (IHF; A-weighted, 500mV out, unity gain)Input Impedance (R and C)56 kilohm + 100pFMaximum Input Signal>4.5Vrms (ref. 0.1% THD)Output ImpedanceSource Z + 200 OhmInput Sensitivity50mV (100Hz ref. 500mV out, Volume maximumMaximum voltage output – IHF load>4.5V (ref. 0.1% THD)
Line In, Headphone Out
THD (20Hz-20kHz)<0.005% at 1V outSignal/Noise Ratio>105dB (IHF; A-weighted, 32 Ohm loads, ref. 2V out, unity gain)Frequency Response±0.3dB (20Hz-20kHz)Channel Separation>56dB at 1kHzOutput Impedance0.5 Ohm
General Specifications
Line In, Speaker Out
Continuous Output Power into 4 Ohms and 8 Ohms (Stereo)>50W (at rated THD, 20-20kHz, both channels driven)IHF Dynamic Power8 Ohm 80W
4 Ohm 150W
2 Ohm 210WTHD (20Hz-20kHz)<0.03% (250mW to 50W, 8 Ohm and 4 OhmSignal/Noise Ratio>98dB (A-weighted, 500mV input ref. 1W out in 8 Ohm)Clipping power>60W (at 1kHz 0.1% THD)Peak output current>18A (in 1 Ohm, 1 ms)Damping Factor>300 (ref. 8 Ohm, 20Hz to 6.5kHz)Frequency Response±0.3 dB (20Hz-20kHz)Channel Separation1kHz >75dB
10kHz >65dBInput Sensitivity (For 50W in 8 Ohm)Line In: 380mV, Digital In: 18% FSSample RateUp to 24 bit/192kHz
Phono In, Speaker Out
THD (20Hz-20kHz) (Stereo)<0.3% at 50W outSignal/Noise Ratio>82dB (200 Ohm source, A-weighted, ref. 500mV out)
>76dB (MM cartridge source, IHF A-weighted, ref. 500mV out)Input Sensitivity4.1mV (ref. 50W 1kHz 4 Ohm out, Volume maximum)Frequency Response±0.3dB (20Hz-20kHz)Input Impedance47 kilohm + 100pFMaximum Input Signal>80mVrms (ref. 0.1% THD)
Power Consumption
at ECO Standby mode 0.4 Watts*at Control Standby mode1.8 Watts**OFF mode (Power switched OFF)0 Watts
