-Frequency Response 52–25,000 Hz ± 3 dB
-Tweeter Dispersion (horizontal x vertical) 80° x 30°
-Sensitivity 95 dB @ 2.83 volts/ meter
-Impedance 4 ohms. Compatible with 4, 6, or 8 ohm rated amps.
-High Frequency Driver 1.25 x 2.4 inch (3.2 x 6.1 cm) Folded Motion XT Obsidian transducer with 4.5 x 2.75 inch (11.4 x 7 cm) diaphragm.
-Crossover Frequency 200, 3200 Hz
-Tweeter Aiming Rotatable tweeter for horizontal or vertical installations
-Mid-Frequency Drivers 6.5-inch (16.5 cm) black unidirectional carbon fiber multi-section cone with Nomex® backer and cast aluminum basket, sealed back chamber format. Concave dust cap.
-Low Frequency Driver Two 6.5-inch (16.5 cm) black unidirectional carbon fiber multi-section cone with Nomex® backer and cast aluminum basket, sealed back chamber format. Concave dust cap.
-Passive Radiators Three 6.5-inch (16.5 cm) unidirectional black carbon fiber cone with Nomex® backer and cast aluminum basket, sealed back chamber format. Concave dust cap.
-Components Custom air core coil inductors, polypropylene film capacitors, and low DF electrolytic capacitors. Thermal/current protection.
-Suitable Amplifier Range 20–300 watts
-Max Power Handling 150 watts
-Binding Post Inputs Push style (two sets for easy installation)
-Weight 44.5 lb (20.2 kg)
-Dimensions (overall size) 46.86 x 10.6 x 4.11 inch (1190.2 x 269.2 x 104.3 mm)
-Required Wall Opening (includes tolerance) 45.57 x 9.29 inch (1157 x 236 mm)
-Projection From Wall Surface 0.31 inch (7.8 mm)
-Depth Behind Wall Surface 3.8 inch (96.5 mm)
-Optional Accessories Pre-install bracket (PN: 7XWBRK)
