Channels / Zones
8 channels / Up to 4 zones
Power Output RMS per Channel (8 Ohm)
60 Watts
Power Output RMS per Channel (4 Ohm)
120 Watts
High Output Mode (Bridged) RMS per Channel (8 Ohm)
200 Watts
Digital-to-Analog Converter
PCM up to 24 bit/192 kHz
Inputs (analog)
4x RCA pairs (left/right)
Inputs (digital S/PDIF)
1x Optical
Inputs (network)
RJ-45 10Base-T/100
Base-TX ethernet port (female)
Inputs (trigger)
1x 3.5mm (5 – 24V DC/AC)
Outputs (speaker level)
4x removable Phoenix style (left/right) accommodate wire up to 12AWG
Outputs (subwoofer)
4x RCA (with bass management and room correction)
Outputs (other)
1x 3.5mm 12V trigger
Audio In-Out Matrix
Yes
Advanced Load Monitoring
Yes
Controls (via web-based UI)
Bass level: ±6dB for each zone;
Trebel level: ±6dB for each zone;
Level balancing: ±10dB for each zone
Controls (back panel)
Power Mode: Auto, Trigger,
External Command;
Network Reset (pinhole);
Factory Reset (pinhole);
Main Power: On /Off
Microphone (for room correction)
Included dual input microphone
(3.5mm and mini-USB)
Setup
Web-based user interface
IP Control (via IP or RS-232)
Drivers for Control4, Crestron, Savant, URC, Elan and RTI(coming soon)
AC Voltage
120V~50/60Hz
Rack Mount Ears / Feet
Included
Rack Space (feet removed)
2U
Dimensions (H x W x D, with feet)
3.9” x 17” x 17” (9.9 x 43.2 x 43.2 cm)
Frequency Response
10Hz – 20kHz ±0.5dB
Room Correction
Anthem Room Correction (ARC®)
Inputs (Other)
Micro-USB (for ARC); RS-232
