Frequency Response
45–20,000 Hz
Recommended Amplifier Power
90 Watts
Sensitivity
90dB
Impedance
Compatible with 8 ohms
Crossover Frequency
2,500 Hz
High Frequency Transducer
1” (2.5cm) titanium dome
Low Frequency Transducer
8” (20.3cm) mineral-filled poly cone
Binding Post Inputs
Push style accommodates wire up to 12AWG
Weight
4.4 lbs. (2 kg)
Dimensions (overall size)
10.4” x 3.98”
(26.4 x 10.1cm)
Cut-Out Dimensions
9-3/8” (23.8cm) dia.
Projection From Wall Surface
0.33” (0.8cm)
Depth Behind Wall Surface
3.65” (9.3cm)
Square Grille (sold separately)
C8 Square Grille
Pre-install Bracket (sold separately)
C8 & C8-AW Bracket
