Application:
Wide dispersion & wide range center
System Type:
4 driver, 3 way
Tweeter:
1" dual pole AMT folded ribbon
Midrange:
5.25" Silver Graphite woven diaphragm, cast basket, phase compensation plug
Midwoofer:
Dual 8" Silver Graphite woven diaphragm, cast basket, phase compensation plug
Low Frequency Alignment:
4th Order Butterworth, dual rear ported
Inputs:
2 pair binding posts for Treble and Bass
Recommended Amplification:
15 - 250 Watts
Freq. Response (Hz, +/-2dB):
41-25K
Impedance:
4 Ohm
Sensitivity:
93.5 dB (2.83V @ 1m)
Crossover (Hz):
500, 3k
Dimensions (HxWxD, inches):
10 x 32 x 10
Weight:
56 lbs each
Shipping Weight:
65 lbs
