Application:
Low profile articulate full range main or side channel
System Type:
4 driver, 3 way
Mounting:
Wall mount with bracket
Tweeter:
4" AMT folded ribbon
Midwoofer:
7" Silver/Graphite woven diaphragm, cast basket, phase compensation plug
Bass:
10" long throw low-profile motor
Passive Radiator:
10" mass loaded pneumatic
Low Frequency Alignment:
Assisted B6
Inputs:
1 pair binding post, recessed cup
Recommended Amplification:
25-300 Watts
Freq Response (Hz, +/-3dB):
42-28k
Impedance:
4 Ohm
Sensitivity:
92 dB (2.83V @ 1m)
Crossover Frequency (Hz):
250, 2.5k
Dimensions (HxWxD, inches):
35.5 x 13.125 x 4.6 (add 5/8" to depth if grille required)
Weight:
50 lbs each
