Power Rating
660 watts per channel x 7 @ 4 ohms, all channels driven 610 watts per channel x 7 @ 8 ohms, all channels driven
Peak Power
1.2 kW peak power from any channel @ 4 Ohm/ 1kHz with less than 1% distortion
Over Current Protection
Breaker reset for excessive sustained current
Inputs
Fully balanced XLR, single-end RCA
Outputs
Gold plated safety approved five-way binding posts
Damping factor
750 average, 20Hz to 1kHz
Voltage Gain
25.8 dB
Dynamic Range
127 dB, A-weighted
Voltage/Current
98 Vp/ 38Ap
Input Sensitivity
5.0 Vp @ 1200W/4 Ohm
Input Impedance
38 kOhm for both pin 2+ and pin 3-
Channel Separation
120 dB at 1kHz
Unit Weight
31 lbs
Unit Dimensions
17.5" W x 15.6" D x 5.8" H
Notes
Highest power output can be obtained using a single 230V, 20A line or dual 120V, 20A lines. A conventional single AC cord is provided. A dual headed AC cord can also be provided for use with power filtration systems with multiple circuits.
