The Cayin Soul 170HA, featuring Tung-Sol KT170 tubes, is a high-performance single-ended Class A amplifier designed for audiophiles. It delivers up to 18 watts per channel with exceptional clarity and dynamic range, powered by a dual-box outboard power supply that minimizes noise and interference.

Key Features:

Single-ended Voltage Amplification: Uses 6SN7 tubes for low noise and balanced sound.
Dual Operation Modes: Switch between Triode Mode for smooth sound and Ultralinear Mode for dynamic, expansive audio.
Impedance Matching: Three outputs (Low, Mid, High) ensure compatibility with a wide range of headphones.
Dynamic Auto Bias: Simplifies tube replacement with automatic adjustment, enhancing safety and tube lifespan.
Elegant Design: Matte black aluminum, North American walnut side panels, and a stylish VU meter combine functionality with aesthetics.
The Soul 170HA offers an immersive audio experience with meticulous craftsmanship and innovative features, ideal for those seeking high-end sound quality.

Cayin SOUL 170HA Flagship tube headphone amp (Call/Email For Availability)

$9,999.00

Features

Premium, powerful vacuum tube-based amp for headphones or home speakers
Features 1st implementation of matched pair of Tung-Sol KT170 tubes in a single-ended architecture Class A headphone amp
Authoritative 18W per channel speaker output at 8Ω and max 18W headphone output via XLR Balanced
6.3mm (3.5mm), 4.4mm Balanced, and 4-pin XLR Balanced headphone out
3 level impedance matching
Separate power supply chassis for cleaner, low-noise power
Ultra-premium, heavy-weighted umbilical power supply cables with quick release connectors

Connectivity

Tubes:
Output: TUNG-SOL KT170 x2
Driver: JJ 6SN7 x2
Rectifier: JJ GZ34S x2
Analog Inputs: XLR (x1 pair), RCA (x1 pair)
Output Power:
3.5mm Single-ended
Ultralinear: 11W (L); 13.5W (M); 17W (H)
Triode: 7W (L); 8.5W (M); 11W (H)
4-pin XLR
Ultralinear: 15W (L); 17W (M); 18W (H)
Triode: 12W (L); 14W (M);15W (H)
4.4mm Balanced
Ultralinear: 2.5W (L); 3.5W (M); 4W (H)
Triode: 2W (L); 2.4W (M); 3W (H)
Speaker: Ultralinear: 18W (8Ω); TR: 10W (8Ω)
THD: 1% (1kHz, 7W/UL, <5% Rated Output)
S/N Ratio: 109dB (A-Weighted)
Weight (Amplifier): 23.3kg
Weight (Power Supply): 17.2kg
Dimensions (Amplifier): 330mm x 400mm x 231 mm
Dimensions (Power Supply): 330mm x 363mm x 114mm
Power Consumption: 240W (Max)
